Description
Provide one SC fiber connector and Two UTP connector
Fully Complies with IEEE802.3 10Base-T,IEEE802.3u 100Base-TX/IEEE802.3u 100Base-FX,IEEE802.3z 1000Base-FX Standard single mode.
Auto-detection of half/full duplex transfer mode for Tx port
Auto-negotiation of 10/100/1000Mbps rate and Auto-MDI/MDIX for Tx port
Provide switch configuration of half/full duplex transfer mode for Fx port
Extend fiber distance up to 20km for single-mode fiber
6 LED display for Power, FDX/Col, FX (Link/Act), TX (Link/Act), FX 1000, TX 100
Easy-to-view LED indicators provides status to easily monitor network activity
| Standard | IEEE802.3 10BASE-T Ethernet IEEE802.3u 100BASE – TX/FX Fast-Ethernet : IEEE802.3z/ab FX/TX 100M-Ethernet : IEEE802.3x |
| RJ-45 Port | Auto-MDI/MDIX |
| Fiber Port | Fiber Type : SC Wavelength : 1310/1550nm Send-Power : 20dBm(min.) 0dBm(max.) |
| Frequency Offset | ±125,000bps (or ± 100ppm) |
| MTU | More than 9036 bytes |
| Dimensions (WxDxH) | 94x71x27mm (External power) |
| Input Voltage | DC5V1A External power input : AC100V-AC240V/50-60HZ |
| Operation Temperature | 0°C~70°C |
| Store Temperature | -40°C~85°C |
| Humidity | 5%~95% non-condensing |
| Weight | 0.3kg/Piece (External Power) |
